Yayıcı noktasını zamanında otomatik olarak temizleyebilir; 0-999 saat ayarlanabilir; Temizleme fırçası, yayıcı noktayı otomatik olarak temizler, bu da manuel temizleme süresini azaltabilir. Alternatif olarak, birkaç saniye içinde manuel olarak temizlenebilir;
Ana Özellikler:
Technical Data Sheet:
Power Input |
DC24V±5% |
|
Operating Power |
Approx.12W |
|
Ion Generation Mode |
Corona Discharging |
|
Power Supply |
AC2200V |
|
LED Display |
H.V |
When the static is eliminated normally, the green indicator light will light up. |
When the static is eliminated abnormally, the red indicator light will light up |
||
Fan |
When the fan works normally, the green indicator light will light up. |
|
When the fan does not work, the red indicator light will light up |
||
Air volume output |
2.5-4.5m³/min |
|
Decay Time |
1.0 sec @12" |
|
Ion Balance |
±10V |
|
Automatic cleaning time setting |
0-999 hours |
|
Ozone generation amount (ppm) |
Within 0.04ppm (measuring distance 150mm) |
|
Environment Temperature |
0-40°C |
|
Environment Humidity |
20%-70%RH (no condensation) |
|
Dimension |
212x143x90mm |
|
(The bracket is included) |
||
Weight |
1.8 KGS |
|
Warranty |
1 Year |
Çalışma Gerilimi: DC24V
Test Voltajı: ±1000V - ±100V
Sıcaklık: 25°C
Distance |
Ion Type |
300mm |
600mm |
900mm |
Decay Time |
+ |
0.6s |
1.4s |
2.2s |
- |
0.8s |
1.6s |
2.9s |
|
Ion Balance |
+ |
±10V |
||
- |
1. Ölçüm yöntemi: 20PF ve 150 mm Şarj Plakası Monitörü ile ölçülmüştür
2. Çürüme süresi, filtre ekranı takılı olmadığında ve hava hacmi maksimum olduğunda ±1000V - ±100V arasındaki "düşme süresi" anlamına gelir.
3. Şarj Plakası Monitörü, fan çıkışının orta hattında bulunur.
